Troubleshooting

Failures in automated systems can lead to production downtime and inferior quality. Failure mode analysis is easily achieved for maintenance personnel that have access to the archived data. Through automated or ad-hoc analysis, users determine the cause and effect relationships and act to eliminate or reduce the chance of repeat occurrences. Quality personnel can also apply their expertise when researching potential product defects.

Companies who rely on the iba system for troubleshooting

Blank
Blank
Blank
Blank
Blank
Blank
Blank
Blank
Blank
Blank
Blank
Blank

Business Benefits

Blank

Determine

failure modes and root causes

Blank

Reduce

production downtime

Blank

Improve

quality and efficiency

Talk to an Expert

Fill out the form and a Troubleshooting Expert will contact you shortly.

iba_talk_to_expert_en

Talk to an expert

Record data continuously

For localizing failures, automated systems need to be continuously monitored and recorded in order to bring transparency to the process. The iba system provides a global view of the entire automation system and allows for analysis of the interactions between the various components and control systems. The iba system can be easily scaled from a portable tool, ibaPDA-PLC-Xplorer, for troubleshooting random failures to a permanently-integrated system, ibaPDA, that provides 24/7 monitoring.

Convenient data analysis with video images

"A picture is worth a thousand words." - ibaCapture can synchronize video streams to process data collected by ibaPDA. In addition, captured videos can be processed in real-time using ibaVision to acquire data that is not feasible with current sensor technology. ibaAnalyzer provides automated or ad-hoc analysis, whereby users determine the cause and effect relationships and act to eliminate or reduce the chance of repeat occurrences. Adding synchronous video review and analysis to the mix provides users with an extremely powerful troubleshooting tool.

Request a price for ibaPDA-PLC-Xplorer

Get in touch
Thank you for your interest in ibaPDA-PLC-Xplorer

We are happy to send you a non-binding offer, please fill out the form so that we can process your enquiry as soon as possible.

iba_request_a_price_en

Request a price

Example configuration for Troubleshooting

Success Stories

turbine

Optimization of a condition monitoring system

A Condition Monitoring System (CMS) is supposed to monitor the wear of two motors. The CMS calculates characteristic values at regular intervals...

detecting critical vibrations in rolling mills

Detecting critical vibrations in rolling mills

In rolling mills, many vibrations may occur that have negative effects on the life cycle and the state of the plant, but also on product quality.

Acoustical monitoring in the engine testing technology

Acoustical monitoring in the engine testing technology

Test benches at an automobile engine plant had to be retrofitted by the test bench manufacturer to include acoustics analysis.

Products for Troubleshooting

Blank

ibaAnalyzer

ibaAnalyzer is characterized by its broad capability for analyzing and evaluating data. The application is intuitive and offers an advanced set of functions. The license for analyzing measurement files, which have been generated with the iba system, is free of charge.

Learn more

Blank

ibaPDA

As the central core of the iba system, ibaPDA has proven itself as one of the most versatile data acquisition systems for maintenance and production for many years. Among the many powerful features of ibaPDA are asset-agnostic acquisition, high-speed synchronous archiving, and real-time streaming analytics.

Learn more

Blank

ibaPDA-PLC-Xplorer

As an entry-level system, users can deploy ibaPDA-PLC-Xplorer on a smaller scale. This license offers functionality similar to ibaPDA with a limited signal count. Without additional hardware, this is an inexpensive way of measuring, displaying and recording signals from various manufacturers' PLCs.

Learn more

Blank

ibaCapture

ibaCapture, in conjunction with ibaPDA, records video and HMI images synchronously with measurement data. Recording can be done continuously, or triggered by events. Important events can be automatically stored as still images. For historical analytics, ibaAnalyzer can be used to automatically retrieve, align, and display recorded video and HMI images with archived measurement data.

Learn more

Order Information

Please contact your local sales partner

Order no.NameDescription
33.010.000 ibaAnalyzer-V7 Offline analysis package for iba measurement files
33.010.001 ibaAnalyzer-V7-DB* Offline analysis and data generation for SQL or ODBC databases
33.010.004 ibaAnalyzer-V7-DB-Multiuser* Multiuser license for 5 users
33.010.002 ibaAnalyzer-V7-File-Extract* Offline data extraction from an original dat file into a new file (new format)
33.010.410 ibaAnalyzer-InSpectra* Offline vibration analysis (add-on for ibaAnalyzer)
33.010.445 ibaAnalyzer-E-Dat* Offline analysis for external data formats
34.000.100 ibaLicenseService-V2 if more than one license is used per dongle (free of charge)

* Licensing of products marked with an asterisk (*) can be done by a local dongle; or by ibaLicenseService-V2 if more than one license is used or several users need the licenses.

Order no.NameDescription
30.770.064 ibaPDA-V7-64 Basic package with server/client application, for 64 measuring signals
30.770.128 ibaPDA-V7-128 Basic package with server/client application, for 128 measuring signals
30.770.256 ibaPDA-V7-256 Basic package with server/client application, for 256 measuring signals
30.770.512 ibaPDA-V7-512 Basic package with server/client application, for 512 measuring signals
30.771.024 ibaPDA-V7-1024 Basic package with server/client application, for 1024 measuring signals
30.772.048 ibaPDA-V7-2048 Basic package with server/client application, for 2048 measuring signals
30.774.096 ibaPDA-V7-4096 Basic package with server/client application, for 4096 measuring signals
30.778.192 ibaPDA-V7-8192 Basic package with server/client application, for 8192 measuring signals
30.779.999 ibaPDA-V7-unlimited Basic package with server/client application, for unlimited measuring signals
30.770.022 ibaPDA-V7-Data-Store Add-on license for writing two more measurement files (*.dat)
30.770.023 ibaPDA-V7-Ultra-Data-Store Add-on license for additional data-storage, 255 measurement files (*.dat) with 20 signals each. Number of files will be reduced, with more signals.
30.770.024 ibaPDA-V7-Client Extension with one more client
30.770.025 ibaPDA-V7-Multi Client Extension with five more clients
30.001.930 ibaPDA Multistation License extension Multi-station application
30.670.050 ibaPDA-SNMP-Server+ Advanced SNMP Server function
30.670.051 ibaPDA-OPC-UA-Server+ Advanced OPC UA Server function
30.670.052 ibaPDA-IEC61850-Server Add-on license IEC61850-Server

ibaPDA Interfaces

Order no.NameDescription
31.000.001 ibaPDA-Interface-S7-Xplorer Xplorer interface for Simatic S7-200/300/400/1200/1500/WinAC/Logo!
31.000.002 ibaPDA-Interface-Codesys-Xplorer Xplorer interface for Codesys-based systems (V2 and V3)
31.000.003 ibaPDA-Interface-AB-Xplorer Xplorer interface for Allen-Bradley PLC5 and SLC500
31.000.004 ibaPDA-Interface-Sigmatek-Xplorer Xplorer interface for Sigmatek systems
31.000.005 ibaPDA-Interface-TwinCAT-Xplorer Xplorer interface for Beckhoff systems
31.000.006 ibaPDA-Interface-B&R-Xplorer Xplorer interface for B&R systems
31.000.007 ibaPDA-Interface-Logix-Xplorer Xplorer interface for Allen-Bradley Logix systems
31.100.008 ibaPDA-Interface-MELSEC-Xplorer Xplorer interface for Mitsubishi MELSEC systems
31.000.030 ibaPDA-Interface-SINAMICS-Xplorer Xplorer interface for SINAMICS drives
31.000.031 ibaPDA-Interface-SIMOTION-Xplorer Xplorer interface for SIMOTION systems
31.001.044 ibaPDA-Interface-Drive-Xplorer Xplorer interfaces for drives (SIMOTION, SINAMICS)
31.001.005 ibaPDA-Interface-EtherNet/IP EtherNet/IP communication interface
31.001.010 ibaPDA-Interface-HPCI-DGM200P HPCI-DGM200P communication interface
31.001.011 ibaPDA-Interface-LANDSCAN LANDSCAN communication interface (infrared line scanner)
31.001.012 ibaPDA-Interface-LMI-Gocator LMI Gocator communication interface (laser profile sensor)
31.001.013 ibaPDA-Interface-Raytek Raytek communication interface (infrared line scanner)
31.001.026 ibaPDA-Interface-AN-X-DCSNet AN-X Automax communication interface
31.001.030 ibaPDA-Interface-RAW-Ethernet Raw-Ethernet communication interface
31.001.040 ibaPDA-Interface-S7-TCP/UDP S7-TCP/UDP communication interface
31.001.045 ibaPDA-Interface-SCRAM-Net SCRAM-Net communication interface
31.001.046 ibaPDA-Interface-Toshiba-ADMAP JAMI1 Toshiba ADMAP communication interface
31.001.047 ibaPDA-Interface-TC-net Communication interface for Toshiba TC-net network
31.001.055 ibaPDA-Interface-Sisteam-TCPIP Sisteam TCP/IP communication interface
31.001.056 ibaPDA-Interface-TDC-TCP/UDP Simatic TDC TCP/UDP communication interface
31.001.065 ibaPDA-Interface-VIP-TCP/UDP ABB VIP-Protokoll TCP/UDP communication interface
31.001.070 ibaPDA-Interface-EGD Ethernet Global Data Memory communication interface
31.001.075 ibaPDA-Interface-Generic-UDP Generic-UDP/IP protocol communication interface
31.001.076 ibaPDA-Interface-Generic-TCP Generic-TCP/IP protocol communication interface
31.001.080 ibaPDA-Interface-GCOM GCOM für ABB Stressometer communication interface
31.001.090 ibaPDA-Interface-IEC61850-Client IEC61850-Client communication interface
31.001.111 ibaPDA-Interface-OPC-UA-Client OPC-UA-Client communication interface
31.001.112 ibaPDA-Interface-MQTT MQTT communication interface
31.001.220 ibaPDA-Interface-Reflective-Memory Reflective Memory Access communication interface
31.001.350 ibaPDA-Interface-Profinet-CP Profinet CP interface to CP1616 and CP1626

ibaPDA Request Options

Order no.NameDescription
31.001.300 ibaPDA-Request-HPCI HPCI system, HPCI symbolic request channels
31.001.302 ibaPDA-Request-HiPAC Symbolic request channels for Danieli HiPAC PLC
31.001.303 ibaPDA-Request-TwinCAT TwinCAT symbolic request via UDP or ibaBM-eCAT
31.001.310 ibaPDA-Request-S7-DP/PN Simatic S7 system, S7 symbolic request via ibaBM-DP/PN
31.001.311 ibaPDA-Request-S7-UDP Simatic S7 system, S7 symbolic request via UDP, ibaPDA-Interface-S7-TCP/UDP required
31.001.320 ibaPDA-Request-SD Simadyn-D system, Simadyn-D symbolic request channels
31.001.330 ibaPDA-Request-TDC TDC system, Simatic TDC request via FO connection
31.001.340 ibaPDA-Request-X-Pact X-Pact system, X-Pact interface to PROBAS system
31.001.360 ibaPDA-Request-FM458/TDC FM458/TDC system, FM458/TDC request via Profibus
31.001.380 ibaPDA-Request-DTBox-128 Dualis DTBox, 128 signals
31.001.381 ibaPDA-Request-DTBox-1024 Dualis DTBox, 1024 signals
31.001.382 ibaPDA-Request-DTBox-unlimited Dualis DTBox, unlimited number of signals
Order no.NameDescription
30.681.502 ibaPDA-V7-PLC-Xplorer   ibaPDA system for 64 signals, 2 clients, 2 data recordings, standard interfaces plus + S7-Xplorer, AB-Xplorer, B&R-Xplorer, Codesys-Xplorer, Logix-­Xplorer, MELSEC-Xplorer, Sigmatek-Xplorer, TwinCAT-Xplorer
30.001.900 Upgrade-ibaPDA-PLC-Xplorer-Interfaces Upgrade of an existing license ibaPDA-PLC-Xplorer with the latest Xplorer interfaces
30.770.009 Upgrade-PLC-Xplorer to PDA-V7-64 Upgrade to ibaPDA-V7 with 64 signals and PLC-Xplorer interface
31.001.042 ibaPDA-Interface-PLC-Xplorer Extension license for an ibaPDA system with PLC-Xplorer interfaces
31.000.030 ibaPDA-Interface-SINAMICS-Xplorer 1 Xplorer interface for SINAMICS drives
31.000.031 ibaPDA-Interface-SIMOTION-Xplorer 1 Xplorer interface for SIMOTION systems
31.001.044 ibaPDA-Interface-Drive-Xplorer 1 Bundle of SINAMICS and SIMOTION-Xplorer interfaces
61.000.200 Measurement and data evaluation with the iba system 2-day training

1 The interfaces are not included in the ibaPDA-PLC-Xplorer license, but can be licensed additionally.

Order no.NameDescription
30.670.210 ibaCapture-Server-60fps Video recording for up to 60 fps, up to 8 client live-streams
30.670.211 ibaCapture-Server-180fps Video recording for up to 180 fps, up to 16 client live-streams
30.670.212 ibaCapture-Server-480fps Video recording for up to 480 fps, up to 48 client live-streams
30.670.213 ibaCapture-Server-960fps Video recording for up to 960 fps, up to 96 client live-streams
30.670.220 ibaCapture-1CAM-REC 1 camera for recording and display
30.670.221 ibaCapture-4CAM-REC 4 cameras for recording and display
30.670.225 ibaCapture-4CAM-DISP 4 cameras only for display
30.670.230 ibaCapture-1CAM-VIRT 1 virtual camera for recording and display of HMI or ibaVision images
30.670.231 ibaCapture-4CAM-VIRT 4 virtual camera for recording and display of HMI or ibaVision images
30.670.232 ibaCapture-8CAM-VIRT 8 virtual cameras for recording and display of HMI or ibaVision images
30.670.233 ibaCapture-16CAM-VIRT 16 virtual cameras for recording and display of HMI or ibaVision images
30.670.128 Interface GigE-Vision Add-on for GigE-Vision cameras with existing license for  a supported GigE-SDK
30.670.131 Interface GigE-Vision with eBUS Runtime Add-on for GigE-Vision cameras including license for eBUS Runtime
30.670.242 ibaCapture-AddOn-RTSP-Server Add-on for receiving RTSP streams on third-party hardware/software
19.116.011 GigE network card for PCI Express Intel Ethernet I350 T4 V2 SVR
