State-of-the-Art Technology, Reliable and With a Long Service Life
Powerful Industrial PCs
For the demanding tasks in the fields of data acquisition and analysis, iba offers powerful industrial computers which meet the highest standards. The computers stand out by the high product quality coupled with state-of-the-art technology. They are designed for a long service life in a rough industrial environment.
Talk to an Expert
Industrial Computers at a Glance
- Standard system with a hard disk; can be upgraded with up to 3 additional hard disks + 4 hard disks with additional hard disk mounting frame
- Operating system Microsoft Windows 10 IoT Enterprise LTSC
- Suited for process data acquisition and analysis
System test and commissioning of industrial plants
Enhancement options
- RAID 1 system with 2 hard disks and redundant power supply unit
- RAID 6 system with 8 hard disks and redundant power supply unit and a second hard disk mounting frame
ibaRackline-PC
- Robust
- Highly available and reliable
- Suitable for continuous 24/7 operation
ibaRackline-PC CAM
- Frame-accurate video information with ibaCapture
- IP and GigE Vision cameras for fast data processing
- High performance und storage capacity by RAID 5 technology and five 8 TB hard disks
ibaRackline-PC HD
- Efficient process analysis with ibaHD-Server
- RAID 5 technology and five 8 TB hard disks for long-term data acquisition of HD-data
- Additional NVMe-SSD as intermediate buffer optimizes access times
Customized equipment
We offer the PCs in different versions:
- ibaRackline for mounting on 19“ rack
- ibaDeskline as Tower PC
Both computer types have powerful processors and motherboards and run on the Microsoft Windows 10 IoT Enterprise Long-Term Servicing operating system. Moreover, we have equipped the computers with high-performance hard disks in SAS technology. Hence they are extremely robust, highly available and suited reliably for the use on a 24/7 basis. The computers offer 5 PCIe slots for iba cards and another 6 slots for iba extension modules in compact design. All connections, like USB interfaces or connections for external devices, can be reached easily. Cooling is provided by a highly efficient cool ing system. The PCs are configured according to your individual needs. The iba software will be installed according to your order. The computers only leave the production after having been carefully tested.
Compact and mobile
Moreover, we offer the following solutions for mobile use or the use in confined space conditions:
› ibaNotebook Workstation power for mobile use Currently available notebooks are available on request.
› ibaIPC-Fanless Compact, fanless, maintenance free
Accessories
We offer optional extension components for applications with increased demands in terms of system availability and storage capacity:
- Hard disk upgrade (SAS)
- SSD hard disk
- ibaOut-State: PC cards for monitoring temperature and voltage supply with LED status display and alarm outputs
- Additional fans
- Redundant power supply units
- GigE network card for connecting GigE cameras
ibaRackline and ibaDeskline are also available with SSD hard disk on request.
Technical highlights ibaRackline & ibaDeskline
- Processor Xeon E and industrial mainboard with LGA1151 socket and C246 chipset as well as 32 GB DDR4-RAM
- High performance hard disk in SAS technology
- Hard disk mounting frame for up to 4 hard disks
- Optionally with additional hard disk mounting frame for 4 more hard disks
- Power supply unit (single/redundant)
- On board graphics board
- 5 PCIe slots for measuring boards, 1 PCIe x16 slot for SAS controller 1 PCI slot
- 6 special slots for iba extension modules in compact design
- Ports for external devices (keyboard, mouse, network and others)
- USB interface for the dongle on the frontside (concealed installation)
- High efficiency cooling system
- Monitoring of temperature and voltage supply ( optional) with LED status display and alarm outputs
Industrial Computers Functions
Explore Real Applications
Get inspired by product use cases and learn how value is created.
PLC Analysis
Failures in automated systems can lead to production downtime and inferior quality. Failure mode analysis is easily achieved for maintenance personnel…
Learn more
Process Monitoring
Automated real time monitoring of processes, machines and plants is based on acquired measurement data, camera images and calculated characteristic…
Learn more
Condition Monitoring
The iba Condition Monitoring System combines vibration-based characteristic values with process and material data to reliably detect wear on plants.…
Learn more
Quality Control
For documenting the automatically manufactured products, quality data and characteristic values need to be calculated and reliably stored in a quality…
Learn more
Long-Term Analysis
The iba system enables continuous acquisition and long-term storage of process and machine data in high temporal resolution. All data is centrally…
Learn more
Vibration Analysis
For reliable real-time monitoring of vibrations, offline analysis tools for optimization and validation are indispensable. The iba system offers you…
Learn more
CAN-Based Measurement Systems in Industrial Environments
Technical Data Acquisition and Analysis with the iba System
Learn more
Full Transparency for Yard Machines in Mining
To gain full transparency into machine behavior it is important to get a coherent view of how drives, PLC logic, sensors, and mechanical components…
Learn more
The iba System as a Diagnostic Tool for Maritime Applications
In modern marine propulsion systems, reliable and continuous monitoring of all components is essential to prevent failures and plan maintenance…
Learn more
Deterministic Data Acquisition and Transmission via ibaNet-E
With ibaNet-E, iba has developed an Ethernet-based protocol for deterministic transmission of measured values.
Learn more
Edge Analytics: Analyze Process Data Where it is Generated
Edge analytics applications allow you to monitor processes locally in real time based on process data. The locally acquired process data can be…
Learn more
Acquire Data From SIMATIC S7 Controllers
The iba system offers several ways to acquire data from the S7 controllers – the right solution for different requirements.
Learn more
Acquire Data From TwinCAT 2 and 3 Controllers
The iba system offers several ways to acquire data from the TwinCAT or other EtherCAT-based controllers – the right solution for different…
Learn more
Data Acquisition From Allen-Bradley Controllers
The iba system offers several ways to acquire data from Allen-Bradley controllers, especially via EtherNet/IP – the right solution for different…
Learn more
Acquire Data From SIMOTION Motion Controllers and SINAMICS Control Units
The iba system offers various ways to acquire data from SIMOTION and SINAMICS drive controllers – the right solution for different requirements.
Learn more
Acquire Machine Data From SINUMERIK CNC Controllers
Using the ibaPDA-Interface-SINUMERIK-Xplorer interface, data can be recorded directly from Siemens SINUMERIK CNC control systems. The connection and…
Learn more
Improve Crane Uptime Through Intelligent Online Monitoring
Overhead cranes are key components in many production and logistics facilities. It is therefore essential to identify potential fault sources at an…
Learn more
Unlocking the Full Potential of Measurement Data: A Value Creation Approach Through Digitalization
Increasing complexity and process speed pose significant challenges for technology-intensive manufacturing companies. Not only do these factors make…
Learn more
So Near and Yet so Far: From Process Analysis at the Edge to KPIs in the Cloud
The more complex a system is, the greater the number of components involved in the process. However, as these influence each other, the impact of the…
Learn more
Controlling the Central Nervous System: Bus Monitors as a Crucial Digitalization Tool
Data has long since become the most important resource of the 21st century. Modern, decentralized industrial plants use industrial bus systems to…
Learn more
Democratizing Measurement Data – An Approach to Cross-Departmental Value Creation
To fully unlock the potential of measurement data, it must be democratized – made holistically accessible and usable across all user groups.
Learn more
Checking and Certifying Coil Tracking Automatically: Handling Flat Products in an Optimized Way With ibaDatawyzer-ICC
Flat products are manufactured in several process steps, that do not directly follow each other in chronological order. Some products (the so-called…
Learn more
Process Analysis With ibaCapture: Keep an Eye on the Entire Plant With Process Specific Camera Monitoring
Usually, the operator does not have a free view on all components and aggregates from the control panel of a rolling mill. This is why camera systems…
Learn more
Increasing Product Quality by Means of Visual Signals: Online Process Monitoring With ibaVision
The task is to detect rhomboidity during a continuous casting process. This needs to be done to allow timely process adjustments and consequently…
Learn more
Companies That Rely on iba
These leading companies already use this component of the iba system.
Join the 2,500+ Customers Worldwide
Contact us – we look forward to hearing from you! Our experts are happy to answer any questions and help you with any challenges you may face.
Talk to an ExpertSuccess Stories
Read the inspiring success stories of our satisfied customers.
Maximum Grid Security for Offshore Wind Power
GE Vernova Relies on the iba System in Sofia Project
Learn more
From Scrap Basket to Heat Analysis
How Badische Stahlwerke Uses the iba System to Bring Transparency to Scrap Charging
Learn more
Badische StahlwerkeDigital Process Monitoring in Batch Annealing
From Paper Chart Recorders to Modern Data Acquisition: To ensure reliable analysis and visualization of furnace data, Aluminium Norf relies on the iba…
Learn more
Transparent Power Plant Monitoring with the iba System at FPCL
After the nationwide blackout in Pakistan on January 9, 2023, energy producers came under increasing pressure to enhance plant monitoring and to…
Learn more
Digital Process Optimization at thyssenkrupp Electrical Steel
At the cold rolling mill of thyssenkrupp Electrical Steel (tkES) in Gelsenkirchen, the team faced a familiar yet complex challenge.
Learn more
Large-Scale Small-Signal Excitation – Measured by iba
The energy transition is fundamentally reshaping power grids: decentralized generation, volatile energy sources, and increasingly dynamic grid…
Learn more
AI-Powered Coil Strap Detection with ibaVision
In the production of aluminum coils, proper strapping is essential to ensure safe handling and transport.
Learn more
Locating High-Speed Faults with iba
A mining company uses the iba system to maximize the availability of electric rope shovels.
Learn more
AI-generated ImageDigital Process Optimization in Steel Refining at LSV
The heat and surface treatment of steel is a complex and sensitive technical process. With the iba system, LSV implemented a comprehensive solution…
Learn more
A Quick Look at Historical Data
In order to analyze processes efficiently, Neuman Aluminium introduced the iba system in production in 2014. Due to its success, it was rolled out to…
Learn more
With a Unified View of All Process Data: Novelis Relies on the iba System
The commissioning of a new pusher type furnace at their Swiss location prompted Novelis to standardize the acquisition and analysis of process data.…
Learn more
Finding a Needle in a Haystack in Seconds: BILSTEIN Monitors Coils With ibaDatawyzer-ICC
Over 1,600 tons of metal, rolled into coils, pass through the BILSTEIN Group’s production facilities every day. To eliminate the risk of mix-ups, the…
Learn more
“With ibaHD-Server, we have direct access to seven years of historical data”
What began seven years ago with the replacement of paper chart recorders in a pusher-type furnace has evolved into a key pillar of quality assurance…
Learn more
Vibration Monitoring Made Easy: Condition Assessment Using Meaningful Characteristic Values
Reducing complexity by calculating KPIs from vibration and machine data in ibaPDA using ibaInSpectra.
Learn more
“ibaDaVIS gives all users easy access to the data and helps us resolve emerging issues more quickly.”
As the legacy system no longer met operational demands, the BILSTEIN GROUP had to seek out a new solution for process data visualization. Their…
Learn more
Service & Downloads
Download important resources or contact our support team for further assistance.
Please contact your local sales partner for details.
| Order no. | Name | Description |
|---|---|---|
| 40.002006 | ibaDeskline SAS | XEON E, Windows 10 IoT Enterprise LTSC 2021, 1200 GB SAS HDD |
| 40.002016 | ibaDeskline SAS | XEON E, Windows 10 IoT Enterprise LTSC 2021, 1600 GB SAS SSD |
| 40.004308 | ibaRackline SAS | XEON E, Windows 10 IoT Enterprise LTSC 2021, 1200 GB SAS HDD |
| 40.004328 | ibaRackline SAS | XEON E, Windows 10 IoT Enterprise LTSC 2021, 1600 GB SAS SSD |
| 40.005021 | ibaRackline-PC CAM | Video and Image Capturing System XEON E, Windows 10 IoT Enterprise LTSC 2021, 5 × 8 TB SAS HDD (RAID 5) |
| 40.005031 | ibaRackline-PC HD | XEON E, Windows 10 IoT Enterprise LTSC 2021, 5 × 8 TB SAS HDD (RAID 5), 1 × 512 GB NVMe SSD |
